8.7. Production constraints by timeslice

In some sectors it may be the case that a technology can only output a certain amount at a certain time. For instance, solar photovoltaics (PV) don’t produce power in the dark, and thus their output is limited at night.

In this section, we explain how to add constraints to outputs of technologies at certain timeslices. This could either by a maximum constraint, for instance with the solar PV example previously mentioned. Or, this could be a minimum constraint, where we expect a minimum amount of output by a nuclear power plant at all times.

8.7.1. Minimum timeslice

In this tutorial we will be amending the default example, which you can find here. Firstly, we will be imposing a minimum service factor for gasCCGT in the power sector. This is the minimum that a technology can output per timeslice.

To do this, we will need to create a new csv file that specifies the minimum service factor per timeslice.

An example of the file can be seen below, and downloaded here.

ProcessName	RegionName	Time	month	day	hour	UtilizationFactor	MinimumServiceFactor
Unit		Year
gasCCGT	R1	2020	all-year	all-week	night	1	1
gasCCGT	R1	2020	all-year	all-week	morning	1	2
gasCCGT	R1	2020	all-year	all-week	afternoon	1	3
gasCCGT	R1	2020	all-year	all-week	early-peak	1	2
gasCCGT	R1	2020	all-year	all-week	late-peak	1	5
gasCCGT	R1	2020	all-year	all-week	evening	1	6
windturbine	R1	2020	all-year	all-week	night	1	1
windturbine	R1	2020	all-year	all-week	morning	1	1
windturbine	R1	2020	all-year	all-week	afternoon	1	1
windturbine	R1	2020	all-year	all-week	early-peak	1	1
windturbine	R1	2020	all-year	all-week	late-peak	1	1
windturbine	R1	2020	all-year	all-week	evening	1	1

Notice that we have to specify the following columns: ProcessName, RegionName, Time, month, day, hour, UtilizationFactor, MinimumServiceFactor

The majority of these columns are self explanatory, and correspond to the columns in other csv files - for instance, ProcessName, RegionName and Time. The timeslice based columns, however, are dynamic and will match the levels as defined in the toml file.

The UtilizationFactor column specifies the maximum utilization factor for the respective technologies in the respective timeslices, and the MinimumServiceFactor specifies the minimum service factor of a technology.

Next, we must link this file to the settings.toml file. This is done by modifying the respective section. As we are modifying the power sector, we have to add it to the following section:

[sectors.power]
type = 'default'
priority = 2
dispatch_production = 'costed'

technodata = '{path}/technodata/power/Technodata.csv'
commodities_in = '{path}/technodata/power/CommIn.csv'
commodities_out = '{path}/technodata/power/CommOut.csv'
technodata_timeslices = '{path}/technodata/power/TechnodataTimeslices.csv'

Notice the technodata_timeslices path in the bottom row of the code above.

For the next part, we want to visualise the output of supply per technology, per timeslice. To do so, we will need to create our own output function. Creating our own output functions will be explored in later tutorials, so don’t worry about understanding the code posted below for now.

Just copy and paste the code below into a python file called output.py and link to it in your settings.toml file as shown below:

plugins = "{path}/output.py"

from typing import List, Optional, Text

import xarray as xr
from muse.outputs.sector import market_quantity, register_output_quantity


@register_output_quantity
def supply_timeslice(
    market: xr.Dataset,
    capacity: xr.DataArray,
    technologies: xr.Dataset,
    sum_over: Optional[List[Text]] = None,
    drop: Optional[List[Text]] = None,
    rounding: int = 4,
) -> xr.DataArray:
    """Current supply."""
    market = market.reset_index("timeslice")
    result = (
        market_quantity(market.supply, sum_over=sum_over, drop=drop)
        .rename("supply")
        .to_dataframe()
        .round(rounding)
    )
    return result[result.supply != 0].reset_index()

To link to our new output supply_timeslice we must past the following code in our settings.toml file.

[[sectors.power.outputs]]
filename = '{cwd}/{default_output_dir}/{Sector}/{Quantity}/{year}{suffix}'
quantity = "supply_timeslice"
sink = "csv"
overwrite = true

Once this has been completed, we are able to run MUSE as before, with the following command:

python -m muse settings.toml

Next, we will visualise the output of the technologies as before. However, this time we will visualise the supply outputs that we created with the previous function per technology and per timeslice.

import matplotlib.pyplot as plt
import pandas as pd
import seaborn as sns

power_supply_2020 = pd.read_csv(
    "../tutorial-code/7-min-max-timeslice-constraints/1-min-constraint/Results/Power/Supply_Timeslice/2020.csv"
)

sns.lineplot(
    data=power_supply_2020[
        (power_supply_2020.commodity == "electricity")
        & (power_supply_2020.year == 2020)
    ],
    hue="technology",
    x="timeslice",
    y="supply",
)
plt.title("Supply versus timeslice for the year 2020")

plt.ylim(0, 10)

(0.0, 10.0)

As expected, for the year 2020, the gasCCGT supplies the electricity mix by the minimum per timeslice. This is as specified in the TechnodataTimeslices.csv file. Starting from a supply of 1 in the first timeslice and ending with a supply of 6 in the last timeslice. The supply increases linearly apart from during the 3rd timeslice, where it reduces to 2.

8.7.2. Maximum timeslice constraint

Next, we want to ensure that the supply of windturbine does not exceed a certain value during the day. This may be because, for example, there is reduced wind during the day. We will, therefore, modify the TechnodataTimeslices.csv file by changing the values of UtilizationFactor.

ProcessName	RegionName	Time	month	day	hour	UtilizationFactor	MinimumServiceFactor
Unit		Year
gasCCGT	R1	2020	all-year	all-week	night	1	1
gasCCGT	R1	2020	all-year	all-week	morning	1	2
gasCCGT	R1	2020	all-year	all-week	afternoon	1	3
gasCCGT	R1	2020	all-year	all-week	early-peak	1	2
gasCCGT	R1	2020	all-year	all-week	late-peak	1	5
gasCCGT	R1	2020	all-year	all-week	evening	1	6
windturbine	R1	2020	all-year	all-week	night	1	0
windturbine	R1	2020	all-year	all-week	morning	0.5	0
windturbine	R1	2020	all-year	all-week	afternoon	0.5	0
windturbine	R1	2020	all-year	all-week	early-peak	1	0
windturbine	R1	2020	all-year	all-week	late-peak	1	0
windturbine	R1	2020	all-year	all-week	evening	1	0

Once this has been saved, we can run the model again (python -m muse settings.toml). Next, we can visualise our results as before. We should hopefully see a reduction in the output of windturbine to 0.5 in the 2nd and 3rd timeslices:

power_supply_2025 = pd.read_csv(
    "../tutorial-code/7-min-max-timeslice-constraints/2-max-constraint/Results/Power/Supply_Timeslice/2025.csv"
)

sns.lineplot(
    data=power_supply_2025[
        (power_supply_2025.commodity == "electricity")
        & (power_supply_2025.year == 2030)
    ],
    x="timeslice",
    hue="technology",
    y="supply",
)
plt.title("Supply versus timeslice for the year 2030")

plt.ylim(0, 10)

(0.0, 10.0)

As expected, we can see an enforced reduction in windturbine output to 0.5 in the 2nd (1) and 3rd (2) timeslices.

8.7.3. Next steps

This brings us to the end of the user guide! Using the information explained in this tutorial, or following similar steps, you will be able to create complex scenarios of your choosing.

For the full code to generate the final results, see here.
